The VPI Dragon is a reference-level turntable engineered to deliver exceptional musical accuracy and low-noise performance. Designed to reveal every detail contained within a vinyl recording, the Dragon combines advanced motor-drive electronics, a mechanically isolated motor assembly, and a precision triple-belt drive system to create an exceptionally stable playback platform.
Its high-mass construction incorporates damped MDF and aluminium materials, while the precision-machined platter and inverted bearing system help minimize vibration and maximize speed consistency. Supplied with VPI’s JMW-10-3D tonearm, the Dragon is designed for demanding audiophiles seeking uncompromising analogue performance.
| Dimension | 543 mm × 400 mm × 400 mm |
|---|---|
| Weight | 26.3 kg |
| Chassis Composition | Vinyl wrapped MDF and steel |
| Power Requirements | 100-120 VAC or 220-240 VAC, 50-60 Hz |
| Platter Type & Size | 304.8 mm aluminium platter, 9.1 kg |
| Tonearm Included | JMW-10-3D tonearm |
| Motor Type | AC synchronous motor |
| Motor Speed | 300 RPM |
| Motor Pulley Accuracy | ±0.0127 mm |
| Drive System | Triple-belt drive |
| Bearing Type | Inverted bearing |
| Wow And Flutter | <0.1% |
| Speed Accuracy | 0.05% |
| Rumble | 80 dB down |
| Footprint | 533 mm × 404 mm × 200 mm |
| Warranty | 5 years |
