L-7000 Preamplifier
SKU: L-7000
$31,800.00

Description

The ALLNIC L-7000 is a reference-level line-stage preamplifier engineered around a minimalist single gain-stage topology and transformer-coupled output design. Developed to preserve the integrity of the original recording, the L-7000 combines exceptional transparency, spatial accuracy, and musical realism with the operational flexibility expected from a modern high-end preamplifier.

A unique aspect of the design is the use of a directly heated triode (DHT) 300B tube as a series voltage regulator rather than as an amplification device. Combined with a true dual-mono architecture, this approach helps provide stable power delivery, excellent channel separation, and low noise performance. The result is a highly detailed and dynamic presentation with lifelike instrument placement, tonal accuracy, and expansive soundstaging.

The L-7000 further distinguishes itself through its transformer-coupled output stage and ALLNIC’s in-house Permalloy-core transformer technology. This design delivers a constant low output impedance across the frequency range while maintaining wide bandwidth and low distortion. A 41-step silver-contact attenuator and remote-control operation complete a package designed for the most demanding audiophile systems.

Specifications

Type Transformer-coupled line-stage preamplifier
Circuit Design Single gain stage
Volume Control 41-step silver contact constant impedance attenuator
Architecture True dual-mono design
Voltage Regulation DHT 300B series voltage regulator
Output Coupling Transformer coupled
Output Impedance 150 Ω (constant)
Transformer Core Material Permalloy (iron-nickel alloy)
Transformer Frequency Response 16 Hz - 50 kHz (-3 dB)
Square Wave Response Up to 20 kHz
Voltage Regulation Performance Less than 1%
Control Remote controlled

Features

  • Uses a 300B directly heated triode as a series voltage regulator.
  • Single gain-stage topology for short and simple signal paths.
  • True dual-mono construction with independent channel operation.
  • Transformer-coupled line output stage.
  • In-house designed and manufactured Permalloy-core transformers.
  • Carefully matched transformer and tube implementation.
  • Constant low output impedance across the frequency range.
  • Wide bandwidth and low-distortion performance.
  • Enhanced current delivery and dynamic capability from tightly regulated power supply.
  • Remote-controlled operation.
  • High-resolution soundstage presentation and accurate tonal reproduction.
