PR200 Signature Amplifier – Soul to Sole Audio

PR200 Signature Amplifier

SKU: PR200-SIG

Brand: Atoll Electronique

$2,295.00

Options

Colour

Make an enquiry →

Description

The PR200 Signature is part of ATOLL’s range of preamplifiers and power amplifiers. This preamplifier represents the modularity and power ATOLL wants to promote: a wide range of combinations and a considerable source of improvements.

Specifications

Power supply	340 VA
Total of capacitors	31 918 µF
Number of inputs	5+1 BY-PASS
Bandwidth	5 Hz – 200 kHz
Rising time	1,3 µs
Input impedance	220 kΩ
Sensitivity	500 mV
Signal/Noise ratio	100 dBA
Distortion at 1 kHz	0,005%
Dimensions	440×300×95 mm
Weight	8 Kg

Features

4 mm brushed aluminium front.
340 VA toroidal transformer.
ALPS motorized potentiometer.
Total of capacitors: 31 918 µF.
Monitoring loop.
Balanced discrete component audio stages.
MKP Technology Link Capacitors.
Double-sided circuit boards with nickel/gold finish.
BY-PASS input.
2 analogue preamp outputs.
12V Trigger output.
ATOLL global remote control.
The PR200 Signature can receive the following optional boards - DAC boards: DA100 and DA200, PHONO boards: P50 and P100 (can be combined with DAC boards)

Connectivity

Inputs: 5 Audio inputs (RCA) / AUX (or optional P50 / P100 phono stage) / CD / TUNER / DVD / TAPE (IN + OUT), 1 BY-PASS input
Outputs: 2 Line preamp outputs (for bi-amplification or to connect a subwoofer), 1 Trigger output (12V), 1 Ø 6,35 mm headphone jack output
Various: Possibility of adding DA100 or DA200 digital boards (optional).
