Phono Module
SKU: PHONO
$4,295.00

Description

What was originally intended to be a simple RIAA add-on for the Makua Preamp has quickly spiraled into the quietest and probably most versatile phono stage ever built. MC/MM input stages are optimized for current noise and voltage noise respectively. Unlike the more common arrangement of an MC head amp feeding into the MM stage, the two stages are fully independent, realizing an equally short signal path for both. Input gain is switchable in 5dB steps over a 40dB range.

Input resistance and capacitance are individually switchable. Available EQ settings cover practically all known cutting curves used, including most 78RPM.

All settings are software controllable, either on the fly using a smart-phone and tablet via the Mola Mola Remote app or directly stored under the preset buttons. The preamp can be configured to route any input through the phono stage, this allows you to have multiple turntables and cartridges connected.

Specifications

Input Noise (MC) 0.35nV/√Hz
Input Noise (MM) 0.9pA/√Hz
Sensitivity Variable from 30uV to 5mV
THD / IMD Not measurable
RIAA Conformance ±0.1dB
Available Time Constant (t1) 200µs, 250µs, 318µs, 400µs, 450µs
Available Time Constant (t2) 50µs, 64µs, 75µs, 100µs
Bass Shelf Adjustment 14dB, 18dB, 20dB

Features

  • Archival-grade phono stage designed for high-end analogue playback.
  • Optimised independently for both Moving Magnet (MM) and Moving Coil (MC) cartridges.
  • Extremely low noise design for maximum signal purity.
  • Adjustable cartridge loading and gain settings for precise system matching.
  • Supports a wide range of equalisation curves, including 78 RPM playback.
  • Software-controlled configuration and preset management.
  • Configurable signal routing for multiple turntables and cartridges.
  • Short signal path architecture for improved transparency and accuracy.
  • Designed to integrate seamlessly with Mola Mola audio systems.
