This discrete DAC is designed to deliver exceptionally accurate digital audio conversion for high-end music systems. Developed using proprietary circuits and in-house digital algorithms, it supports a wide range of digital sources including USB, AES/EBU, Optical, Bluetooth, and network streaming via Roon Ready connectivity.
The design incorporates asynchronous upsampling, advanced jitter reduction, and a discrete conversion architecture to provide precise signal reproduction and compatibility with modern high-resolution audio formats.
| I/O | AES/EBU (XLR), Optical (Toslink), USB Type-B, Bluetooth (SBC, AAC, aptX, LDAC), Ethernet (Roon Ready) |
|---|---|
| Supported PCM Formats | Up to 384kHz / 32-bit (>192kHz and >24-bit via USB and Roon only) |
| Supported DSD Formats | DoP and Native DSD up to Quad Speed (USB and Roon only) |
| Full-Scale Output Level | 20dBu |
| Signal-to-Noise Ratio | 130dB |
| THD / IMD | Not measurable (estimated -140dB) |
| Bandwidth | Up to 80kHz (apodizing response) |
| Integrated Jitter | <1ps from 10Hz upwards, <300fs from 1kHz upwards |
| Jitter Rejection | 80dB at 1Hz after 20 seconds of lock |
| Internal Upsampling | All incoming digital audio upsampled to 3.125MHz / 32-bit |
| DAC Architecture | Dual mono DAC design with discrete 32-stage FIR DAC and single-stage 4th-order filtering I/V converter |
