The AM200 Evolution block is suitable for most HIFI or audio-video applications. Very scalable, it can be used alone or in bi-amplification. It can be associated with an integrated amplifier or an ATOLL preamplifier. It is bridgeable in a monoblock via an internal switch. It is equipped as standard with a 12V Trigger input (direct ignition in conjunction with a preamp).
| Power Wrms/channel/8Ω | 120 W |
|---|---|
| Power Wrms/channel/4Ω | 200 W |
| Pulse power/channel | 300 W |
| Power supply | 2×340 VA |
| Total capacitive | 59,420 µF |
| Number of inputs | 1 RCA |
| Consumption with switch off | 0 W |
| Consumption in operation | 20 W – 600 W |
| Input impedance | 220 kΩ |
| Sensitivity | 1.77 V |
| Signal/noise ratio | 100 dB |
| Distortion at 1 kHz | 0.05% |
| Bandwidth | 5 Hz – 200 kHz |
| Rise time | 1.5 µs |
| Dimensions | 440×295×95 mm |
| Weight | 12 kg |
