The DS Master 3 Equalizer is the matching control and amplification unit designed exclusively for the DS Master 3 Optical Cartridge. Featuring a dual monaural architecture with completely independent left and right channel circuits, the unit is engineered to maximize channel separation, low-frequency authority, and overall musical performance.
Built by hand in Japan, the Master 3 Equalizer incorporates three transformers, balanced and unbalanced outputs, and user-selectable low-frequency cutoff settings to accommodate a wide range of audio systems and listening preferences.
| Output Voltage | 700mV (1kHz) |
|---|---|
| Output Impedance | RCA 120Ω, XLR 120Ω |
| Preamp Input Impedance | More than 10kΩ |
| Input Terminal | RCA Terminal |
| Output Terminal | RCA Terminal ×3, XLR Terminal ×3 |
| Dimension | W45.2cm × H15.3cm × D48.4cm |
| Weight | 23kg |
